48
TRI TOOL INC.
92-0612 Rev. 131230
Parts List, Block Assembly, Jackscrew (P/N 08-0092)
Item Part
No. No. Description Qty
08-0092 BLOCK ASSY, CLAMP 4
1. 19-0262 HOUSING, JACKSCREW 1
2. 32-0043 PIN, ROLL, 3/16 DIA X 1 1/4" 1
3. 33-0110 SCREW, CAP, 1/2-13 X 2 1/4", ZP 4
4. 33-1343 SCREW, ADJUST 1
5. 48-0315 BLOCK, GUIDE 1
26-0478 BAR ASSY, ADJUSTABLE 4
6. 26-0474 BAR, FIXED 1
7. 32-0290 PIN, ROLL, 1/8 DIA X 1/4" 2
8. 33-0077 SCREW, CAP, 3/8-16 X 2 1/2", ZP 2
26-0479 BAR ASSY, ADJUSTABLE 4
6. 26-0475 BAR, FIXED 1
7. 32-0290 PIN, ROLL, 1/8 DIA X 1/4" 2
8. 33-0073 SCREW, CAP, 3/8-16 X 1 1/2", ZP 2
26-0480 BAR ASSY, ADJUSTABLE 4
6. 26-0476 BAR, FIXED 1
7. 32-0290 PIN, ROLL, 1/8 DIA X 1/4" 2
8. 33-0068 SCREW, CAP, 3/8-16 X 5/8", ZP 2
