Installation Guide
Step 2: Install the Camera
1.
If necessary, insert a memory card into the card slot of the camera.
2.
Connect the network cable to the Ethernet port of the camera. If necessary, connect the other
cables (such as power adaptor, DI/DO, etc.) to the corresponding connectors.
3.
Align and insert the camera base hooks to the mounting holes.
4.
Slide the camera clockwise to secure the hooks to the mount.
