Installation Guide
Step 5: Connect and Install the Camera
1.
Connect the network cable to the Ethernet port of the camera and then push the extra length
of cable into the gang box.
2.
Align and insert the hooks on the camera to the slots on the mounting plate.
3.
Slide the camera clockwise until it locks into place.
