6-3 Shutdown
1. Turn off the conveying system supplying the drying hopper.
2. When processing is complete, close the hopper slide gate and shut down any in-line
companion equipment, such as the aftercooler.
3. Level 1 Controls: Turn the On/Off selector switch to OFF .
Level 2 Controls: Push the Run/Stop rocker switch to the OFF position.
The unit shuts off after completing the regeneration cycle.
4. If needed, empty the drying hopper.
5. For maintenance or a long term shutdown, open (de-energize) the electrical disconnects
at the dryer and at the power drop.
6-4 Setting the Process Air Temperature
Level 1 Controllers
To change the process air temperature set point with the dryer running:
1. Press once.
2. Press to raise the set point to the desired temperature.
- or -
Press to lower the set point to the desired temperature.
3. Press twice to restore.
Level 2 Controllers
To change the process air temperature set point with the dryer running:
• Press to raise the set point to the desired temperature.
• Press to lower the set point to the desired temperature.
WDMR and WDFR Series Dehumidifying Dryers Page 43
