LEGEND:
NS= Not Shown
* Use these codes to designate color needed:
** =Purchase locally
01-White
02-Gloss Black
03-Gray
04-Allmand Yellow
05-Orange
06-Allmand Gold
09-Flat Black
10-High temp Black
11-Red
MAXI-LITE ML 15/ML 20 SERIES
P A R T S R E F E R E N C E
49
NO
REQ’D
PART NO
DESCRIPTION
C-8D
ELECTRIC WINCH, SLACK LIMIT SWITCH, AND TOWER SUPPORT
1
2
046050
5/16 -18 NC X 1 GRADE 5 BOLT
2
7
046110
3/8 - 16 NC X 1 GRADE 5 BOLT
3
1
680111*
TOWER PIVOT WELDMENT
4
4
044031
5/16 - 18 NC KEPS NUT
5
7
044036
3/8 -16 NC KEPS NUT
6
1
046200
1/2 - 13 NC X 2 1/4 GRADE 5 BOLT
7
6
047015
3/8 FLAT WASHER
8
1
630157
STRONG ARM ELECTRIC WINCH
352478
EMERGENCY WINCH HANDLE
9
1
680142*
STRONG ARM WINCH COVER
10
4
041075
5/16 - 18 NC SELF TAPPING SCREW
11
1
320112
2 1/2 PULLEY W/BUSHING
12
1
044048
1/2 - 13 NC NYLON INSERT NUT
13
2
041007
#6 - 32 NC X 1 1/2 ROUND HEAD SCREW
14
2
047005
1/4 FLAT WASHER
15
1
466093
SLACK LIMIT SWITCH
16
1
352056*
SLACK LIMIT SWITCH MOUNT BRACKET
17
2
047047
#6 FLAT WASHER
18
2
044004
#6 - 32 NC HEX NUT
19
1
352089*
TOWER KICK OUT SPRING
20
2
047010
5/16 FLAT WASHER
21
1
090232
DECAL-CORRECT WINCH OPERATION
A.S.(NS) 1
352151
OPTIONAL WORKLIGHT
A.S.(NS) 1
352146
WORKLIGHT MOUNTING BRACKET
