Configuration and Monitoring
Local Mode Configuration
Set the operating mode for each channel using the two local onboard
control components described below and shown in
Figure 16 on page 25 .
Operating modes are described in Operating Modes Overview on page 23 .
• Function (rotary) switch (S2) – this switch is used to access each of the
four channels for configuration. The switch has 16 possible positions (0
through 9 and A through F). Only positions 1, 2, 3, 4, and F are used (see
Table 4 ).
Note The Function switch should be parked in an unused position such as 0 during
normal operation to avoid changing the mode accidently with the paddle
switch.
• Paddle switch (S1) – scrolls through the available modes for the selected
channel when the switch is held momentarily in either the up or down
position.
• CONFIG (configuring) LED – when on, indicates the module is initial-
izing or processing configuration information.
Table 4. Mode Configuration Functions
Function
Switch
Setting
Paddle
Switch Up
Paddle
Switch Down
Function Description
0 – – Park position for normal operation (paddle switch has no effect)
1 Increment Decrement
Set Channel 1 operating mode as Auto/Mute, Fixed 270M/Mute,
Fixed 1.5G/Mute, Auto/Bypass, or Fixed Bypass.
2 Increment Decrement
Set Channel 2 operating mode as Auto/Mute, Fixed 270M/Mute,
Fixed 1.5G/Mute, Auto/Bypass, or Fixed Bypass.
3 Increment Decrement
Set Channel 3 operating mode as Auto/Mute, Fixed 270M/Mute,
Fixed 1.5G/Mute, Auto/Bypass, or Fixed Bypass.
4 Increment Decrement
Set Channel 4 operating mode as Auto/Mute, Fixed 270M/Mute,
Fixed 1.5G/Mute, Auto/Bypass, or Fixed Bypass.
5-9 – –
Not used
A-E – –
F Recall
Recall factory defaults (all channels have Reporting Enabled and
Auto/Mute mode selected).
