8995UPC/DNC/UDX — Instruction Manual 115
View Select (Choose audio streams
to view for audio delay adjustments)
Streams (1-2)
Streams (1-2),
Streams (3-4),
Streams (5-6), or
Streams (7-8)
Audio Delay/
Stream (1-2), Streams (3-4), Streams (5_6) or
Streams (7-8) radio button
N/A
Lock Channels A and B together in
each stream for delay adjustment
(stereo)
Unlocked Lock or Unlock
Audio Delay/
Streams (1-2), Streams (3-4), Streams (5-6),
and Streams (7-8)
Channel Lock checkbox
AudChLk-1-8
Set Channel A and Channel B delay
for each audio stream 1-8
0mSec
59.94Hz:
-33.786 to +33.786ms
50Hz:
-40ms to +40ms
23.98Hz
-41.708ms to +41.708ms
Audio Delay/
Stream (1-2), Streams (3-4), Streams (5-6), and
Streams (7-8)
ChA/ChB Delay Adjust controls (mSec)
AudChDly-1-16
Choose embedded audio streams to
view and adjust
Streams (1-2)
Streams (1-2),
Streams (3-4),
Streams 5-6),
or Streams (7-8)
Audio Gain/
View Select
Streams (1-2), Streams (3-4),
Streams 5-6), Streams (7-8) radio buttons
N/A
Lock Stream 1-8 Channels A and B
together for gain adjustment (stereo)
Unlock Lock or Unlock
Audio Gain/
Channel A and Channel B
Gain Lock checkbox
AudChLk1-8
Set audio gain for Channel A and
Channel B in Streams 1-8
in Groups 1-4 0 dB -40 to +6 dB
Audio Gain/
Channel A Gain control
Channel B Gain control AudChGn1-16
Select Audio groups for channel
pairing
Groups (1-2)
Groups (1-2)
Groups (3-4)
Audio Channel Pairing/
View Select
Groups (1-2) and Groups (3-4)
radio buttons
N/A
Define audio In1 and In2 for Pairs 1-
2 and 3-4 in Groups 1-2 and 3-4
from available channels.
See Range/Choices at
right
Force Silence
SDI Input G1.S1.ChA
SDI Input G1.S1.ChB
SDI Input G1.S2.ChA
SDI Input G1.S2.ChB
SDI Input G2.S1.ChA
SDI Input G2.S1.ChB
SDI Input G2.S2.ChA
SDI Input G2.S2.ChB
SDI Input G3.S1.ChA
SDI Input G3.S1.ChB
SDI Input G3.S2.ChA
SDI Input G3.S2.ChB
SDI Input G4.S1.ChA
SDI Input G4.S1.ChB
SDI Input G4.S2.ChA
SDI Input G4.S2.ChB
Audio Channel Pairing/
Group (1-2) and (3-4)
In1 and In2 for Pairs 1-4 in Groups 1-4
Channel A and Channel B for each stream
radio buttons
AudOut1-16
View Select audio Group 1, Group 2,
Group 3, or Group 4 for type of
audio processing to be re-embed-
ded to SD output.
(Note: Audio Re-embedding check-
box on Video Out web page must be
checked to re-embed audio to out-
put.
Group 1
Group 1,
Group 2,
Group 3,
or Group 4
Audio Proc/
Audio Re-Embedding to SDI Output
View Select
Group 1, Group 2, Group 3, or Group 4
radio button
N/A
Table 13. Summary of 8995UDX/UPC/DNC Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
