EDIUS HD (RX-E1)
Video Format
Input /
Output
Signal
Format
HD-Mode
HD-SDI 10bit (SMTPE 259M-C
Compatible)
SD-Mode
SDI 10bit (SMTPE 259M-C
Compatible)
Spported
Formats
HD-Mode
1920 x 1080 / 59.94i
1920 x 1080 / 50i
1920 x 1080 / 24PsF
1920 x 1080 / 23.98PsF
1920 x 1080 / 29.97PsF
1920 x 1080 / 25PsF
SD-Mode
720 x 486 (NTSC) or 720 x 576
(PAL)
Uncompressed PAL / NTSC
(ITU-R601)
Internal Signal
Processing Format 4:2:2 input / Output 10bit
(Internal processing 8bit)
Video
Input
Terminal
HD /
SD-SDI
(Shared by
HD / SD)
BNC x 1
HD Ref
BNC x 1
(Tri-level Sync, 75 ohm)
SD Ref
BNC x 1
(Black Burst Signal, 75 ohm)
Output
Terminal
HD /
SD-SDI
(Shared by
HD / SD)
BNC x 2
Audio
Input
Terminal Embedded
Audio BNC x 1 (SMPTE 299M / 272M-
A Compatible)
Output
Terminal
Embedded
Audio BNC x 1 (SMPTE 299M / 272M-
A Compatible)
Analog
Monitor LINE OUT x 1
(Output from a Sound Card)
Audio Format Embedded Audio
SMPTE 299M / 272M-A
Compatible
Control
Terminal
Remote Control RS-422A D-sub 9pin x 1
