34
Specifications
Kaleido-MX 4K Control
Kaleido-MX 4K Control
Reference Inputs
The Kaleido-MX 4K (1RU) models support one external reference input for system genlock.
LTC Inputs
The Kaleido-MX 4K (1RU) models support one unbalanced LTC input for clock
synchronization.
Communication
Reference Input
Supported formats SMPTE ST 170
SMPTE ST 318
ITU 624-4
BT 470-6
SMPTE ST 274
SMPTE ST 296
Connector DIN 1.0/2.3
LTC Input
Signal SMPTE ST 309-1999, SMPTE ST 12-1995 (EBU-3259-E)
Level 500 mVp-p to 10 Vp-p
Impedance >12 k
Connector DIN 1.0/2.3
Ω
Ethernet (3)
Signal 10/100 BASE-T
Standard IEEE 802.3
Connector RJ-45
Serial port
Signal RS-422 (SMPTE ST 207, EBU-3245), RS-485
Connector RJ-45
USB (2)
Standard USB version 2.0
