GUIDE TO INSTALLATION AND OPERATION
18 | Kaleido-Solo
5.3 Metadata Menu
This menu is used to configure the parameters needed to correctly extract different metadata types - for example, the
aspect ratio packet, time code packet or the Dolby metadata packet.
Status
Some statuses are reported directly in this menu for the ease of configuration.
AR Status: Aspect ratio status shows the presence of an AFD code following the selected aspect ratio
parameters (Detected or N/A).
TC Status: Time code status shows the presence of time code (Detected or N/A).
DM Status: Dolby metadata shows the presence of the selected SDID (Detected or N/A).
