GUIDE TO INSTALLATION AND OPERATION
42 | Kaleido-Solo
ALM Standard – ALM 5.1 (1 and 2)
Off Hide the 5.1 audio level meters giving the space to show up to 3 stereo audio level meters.
Other types See ALM1,2,etc type for more details.
ALM Standard - ALM1, ALM2, etc.
For each of the eight available ALMs,
Off Hide the stereo meter.
Other types See next picture and next table to see all representation supported.
1 Linear (Digital type VU (Green bars) + Peak (White horizontal lines))
2 EBU Digital (Digital type VU (Green bars) + Peak (White horizontal lines)) (IEC60268-18)
3 VU Meter (Analog VU) (IEC60268-17)
4 UK PPM (Analog peak) (IEC60268-10 type IIa)
5 EBU PPM (Analog peak) (IEC60268-10 type IIb)
6 Nordic PPM (Analog peak) (IEC60268-10 type I)
7 DIN PPM (Analog peak) (IEC60268-10)
