13
Configuration
Chapter 4 provides configuration instructions for the NV9604.
Topics
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adding a Panel to an NV9000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
NV9604 Panel Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Commitment Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Panel Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Button Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
This chapter addresses configurers. Operators and other persons not interested in NV9604
configuration need not read this chapter.
Summary
The NV9604 is a relatively simple panel. It has 32 function buttons. It can operate stand-alone as
a single-destination panel or as a limited X-Y panel. It can also operate as an extension to an
NV9602 control panel. As an extension, it follows the mode in which the NV9602 was config-
ured. The NV9602 has 4 operating modes:
• Single-Destination Mode .
• Single-Destination Mode with Breakaway .
• Limited X-Y Mode .
• Multi-Destination Mode .
NV9000-SE Utilities is the software with which to configure the NV9604. Figure 4-1, following,
shows the default NV9604 panel configuration page from NV9000-SE Utilities.
Adding a Panel to an NV9000 Configuration
You must create configurations for the NV9604 using NV9000-SE Utilities. We assume that you
are familiar enough with NV9000-SE Utilities that you can understand the following material. It
is not difficult material, but some of the concepts might not be familiar to everyone.
It takes only a few seconds to add a new panel configuration.
