Trinix — Installation and Service Manual 51
Appendix
4
Specifications
Mechanical
Environmental
Air Intake/Exhaust Locations
All modules draw cooling air through fans in the front. Warm air is
exhausted through openings in the back. It is not necessary to leave open
space above or below the chassis.
Table 1. Mechanical Specifications
Depth
, a
a Allow a minimum of 6 in. (152 mm) of clear space at the rear of the MCP for proper cable clearance and air flow.
Width Height Weight
b
b All weights approximate.
Rack Units
TRX-PS-BU1200 11.56 in. / 294 mm 19.0 in. / 483 mm 1.75 in. / 44 mm 7.2 lb. / 3.2 kg 1
TRX-PS-BU2400 11.56 in. / 294 mm 19.0 in. / 483 mm 1.75 in. / 44 mm 10.3 lb. / 4.6 kg 1
Table 2.
Environmental Characteristics (operation with required forced air cooling)
Operating temperature 32 to 104 degrees F (0 to 40 degrees C) ambient
Full specifications met 32 to 104 degrees F (0 to 40 degrees C)
Storage temperature -40 to 185 F (-40 to +85 degrees C)
