Vertigo XG Configuration Guide 1-1
1 I
NTRODUCTION
The Vertigo XG is a full-featured HD/SD graphics processor that provides high performance
single or dual channel graphics rendering and video playback performance. The Vertigo XG
is ideal for a wide range of advanced real-time broadcast applications, like HD/SD dual-
casting with independent graphics for HD and SD, and single channel applications
demanding sophisticated, multi-channel branding and promotional graphics.
The main purpose of this Configuration Guide is to provide practical reference and
procedural information on how to use the Vertigo XG’s desktop and remote configuration
applications to configure the Vertigo XG graphics processing system.
The following sections of this configuration guide describe the Vertigo XG’s features,
capabilities, and system integration:
•
“Vertigo XG’s standard and optional features” on page 1-2
• “Vertigo XG system integration” on page 1-4
• “Simulcast downstream branding using the Vertigo XG” on page 1-6
Further chapters provide descriptions of the Vertigo XG’s hardware and software
components:
•
“Overview of the Vertigo XG’s Hardware” on page 2-1
• “Vertigo XG’s Desktop Applications & Tools” on page 3-1
Most Vertigo XG devices are installed and configured by qualified network administrators or
Grass Valley’s Integration Specialists using the Vertigo XG Portal and Dashboard software
interfaces. While we do not recommend that users change the Vertigo XG’s settings, the
following chapters provide detailed descriptions of each of the Vertigo XG settings:
•
“Vertigo XG Portal - Vertigo XG’s Remote Configuration Tool” on page 4-1
• “Dashboard - Vertigo XG’s Local Configuration Software” on page 5-1
