9
USB Type A
Data I/O
1 2 3 4
/ Data (-) Data (+) Data
GND
10
RJ-45
Remote Footswitch and keypad
1 2 3 4 5 6 7 8
Case
GND S-2
NO S-1
NO / S-1 and S-2
CO
/ / /
Remote Footswitch Wiring
8
Audio out
1 2
Out Signal GND
7
V.24/RS-232-C
1 2 3 4 5 6 7 8 9
/ TXD RXD DTR Signal
GND
DSR RTS CTS /
6
Parallel Input/Output Port
2 3 4 5 6 7 8 9 1 14 16 17 18
Data
Out 1
Data
Out 2
Data
Out 3
Data
Out 4
Data
Out 5
Data
Out 6
Data
Out 7
Data
Out 8
Data
Out 9
Data
Out 10
Data
Out 11
Data
Out 12
Signal
GND
15 13 12 11 10 19 20 21 22 23 24 25 –
Data
In 1
Data
In 2
Data
In 3
Data
In 4
Data
In 5
Signal
GND
Signal
GND
Signal
GND
Signal
GND
Signal
GND
Signal
GND
Signal
GND
/
