48 3 Touch Probe Cycles for Automatic Workpiece Inspection
3.1 Measur
ing W
o
rk
piece Misalignment
3.1 Measuring Workpiece
Misalignment
Overview
The TNC provides five cycles that enable you to measure and
compensate workpiece misalignment. In addition, you can reset a
basic rotation with Cycle 404:
Cycle Soft key Page
400 BASIC ROTATION Automatic
measurement using two points.
Compensation via basic rotation. Page 50
401 ROT OF 2 HOLES Automatic
measurement using two holes.
Compensation via basic rotation. Page 52
402 ROT OF 2 STUDS Automatic
measurement using two studs.
Compensation via basic rotation. Page 55
403 ROT IN ROTARY AXIS Automatic
measurement using two points.
Compensation by turning the table. Page 58
405 ROT IN C AXIS Automatic alignment
of an angular offset between a hole
center and the positive Y axis.
Compensation via table rotation. Page 62
404 SET BASIC ROTATION Setting any
basic rotation. Page 61
