M109
M110
M111
Constant contouring speed at tool cutting edge
(increase and decrease feed rate)
Constant contouring speed at tool cutting edge
(feed rate decrease only)
Cancel M109/M110
M114
M115
Automatic compensation of machine geometry when working with tilted axes
Reset M114
M116
M117
Feed rate for rotary axes in mm/minn
Cancel M116
M118
Superimpose handwheel positioning during program run
M120
Pre-calculate radius-compensated contour (LOOK AHEAD)
M124
Do not include points when executing non-compensated line blocks
M126
M127
Shortest-path traverse of rotary axes
Cancel M126
M128
M129
Retain position of tool tip when positioning tilting axes (TCPM)
Cancel M128
M130
Moving to position in an untilted coordinate system with a tilted working plane
M134
M135
Exact stop at nontangential contour transitions when positioning with rotary axes
Reset M134
M136
M137
Feed rate F in millimeters per spindle revolution
Reset M136
M138
Selection of tilted axes
M140
Retraction from the contour in the tool-axis direction
M141
Suppress touch probe monitoring
M142
Delete modal program information
M143
Delete basic rotation
M144
M145
Compensating the machine’s kinematics configuration for ACTUAL/NOMINAL
positions at end of block
Reset M144
M148
M149
Retract the tool automatically from the contour at NC stop
Cancel M148
M150
Suppress limit switch message (function effective blockwise)
M200
M201
M202
M203
M204
Laser cutting: Output programmed voltage directly
Laser cutting: Output of voltage as a function of distance
Laser cutting: Output of voltage as a function of speed
Laser cutting: Output of voltage as a function of time (ramp)
Laser cutting: Output voltage as a function of time (pulse)
N
Effect
Effective at block... Start
End
Page
