Using touch probe cycles – HEIDENHAIN iTNC 530 (340 49x-06) Cycle programming User Manual
Page 34
34
13.1 General Information about Touch Probe Cycles ..... 312
Cycles in the Manual and El. Handwheel modes ..... 313
Touch probe cycles for automatic operation ..... 313
13.2 Before You Start Working with Touch Probe Cycles ..... 315
Maximum traverse to touch point: MP6130 ..... 315
Safety clearance to touch point: MP6140 ..... 315
Orient the infrared touch probe to the programmed probe direction: MP6165 ..... 315
Consider a basic rotation in the Manual Operation mode: MP6166 ..... 316
Multiple measurement: MP6170 ..... 316
Confidence interval for multiple measurement: MP6171 ..... 316
Touch trigger probe, probing feed rate: MP6120 ..... 317
Touch trigger probe, rapid traverse for positioning: MP6150 ..... 317
Touch trigger probe, rapid traverse for positioning: MP6151 ..... 317
KinematicsOpt: Tolerance limit in Optimization mode: MP6600 ..... 317
KinematicsOpt, permissible deviation of the calibration ball radius: MP6601 ..... 317
