72 First steps with the iTNC 530
1
.3 Pr
ogr
amming the first par
t
 Contour departure
 Select the departure function DEP CT
 Center angle? Enter the departure angle, e.g. 90°, and
confirm with the ENT key
 Circle radius? Enter the departure radius, e.g. 8 mm,
and confirm with the ENT key
 Feed rate F=? Enter the positioning feed rate, e.g.
3000 mm/min and confirm with the ENT key
 Miscellaneous function M? Switch off the coolant,
e.g. M9, with the END key: The TNC saves the entered
positioning block
 Retract the tool: Press the orange axis key Z in order
to get clear in the tool axis, and enter the value for the
position to be approached, e.g. 250. Confirm with the
ENT key
 Confirm Radius comp.: RL/RR/no comp? by pressing
the ENT key: Do not activate the radius compensation
 Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
 Miscellaneous function M? Enter M2 to end the
program and confirm with the END key: The TNC
saves the entered positioning block
Further information on this topic
 Complete example with NC blocks: See "Example: Linear
movements and chamfers with Cartesian coordinates" on page 240
 Creating a new program: See "Creating and writing programs" on
page 113
 Approaching/departing contours: See "Contour approach and
departure" on page 223
 Programming contours: See "Overview of path functions" on page
231
 Programmable feed rates: See "Possible feed rate input" on page
117
 Tool radius compensation: See "Tool radius compensation" on page
212
 Miscellaneous functions (M): See "Miscellaneous functions for
program run control, spindle and coolant" on page 373
