Programming: Q Parameters
9.8 Additional functions
9
290
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
9.8 Additional functions
Overview
Press the DIVERSE FUNCTION soft key to call the additional
functions. The TNC then displays the following soft keys:
Function Soft key Page
FN 14:ERROR
Displaying error messages
291
FN 16:F-PRINT
Output of formatted texts or Q
parameter values
295
FN 18:SYS-DATUM READ
Reading system data
299
FN 19:PLC
Transfer values to the PLC
308
FN 20:WAIT FOR
NC and PLC synchronization
308
FN 29:PLC
Transfer up to eight values to the PLC
310
FN 37:EXPORT
Export local Q parameters or QS
parameters into a calling program
310
FN 26:TABOPEN
Opening a freely definable table
405
FN 27:TABWRITE
Write to a freely definable table
406
FN 28:TABREAD
Read from a freely definable table
407
