7
Laney
CXSub Facilities
CXsub
Unlike the other products in this brochure
the CXsub is a passive cabinet - this means it
does not require any mains power but just
needs to be driven by a power amplifier or
the extension speaker socket on an active
loudspeaker.
All the CX-A cabinets feature extension
speaker sockets - these are ideal for driving
the CXSub cabinet. If you have an application
where you need more bass the CXSub is the
perfect solution.
Input
Connect either the power amplifier speaker
output or your CX-A extension speaker
socket . Connections to this socket should
always be on good quality speaker cable.
Link
A Link connection is provided for daisy
chaining another speaker cabinet. This saves
you having to obtain a Y splitter for driving 2
cabinets from 1 amplifier speaker output.
Important : In a system which uses CX-A
active loudspeakers an `extension speaker
socket` can only drive 1 unpowered 8 ohm
cabinet.
1
1 2
www.laney.co.uk
2
www.laney.co.uk
Link
Designed in the UK by Laney Serial Number: Serial Number:
Input
Made in China
Laney
Power To The Music
N164 6 N164 6
www.laney.co.uk
Model:
Impedance :
Power Rating: CXSub
8 ohm
500W Program
250W RMS
