Board Layout
Chapter 3
Embedded and Industrial Computing
Chapter 3:
Board Layout
External Connectors
The following picture highlights the location of internal
connectors and jumpers. Refer to the table 3.1 Connector
List for more details.
POEIO1 (on the back)
ATX1
USB2
CAN1
COM2
COM1
MIO1
LAN1
HDMI1
VGA1
PRJK1
