2.0 Installation
© 2012 Magnum Energy, Inc. 4
2.0 Installation
Installing the AGS is a simple process. Before installing, read this entire
section so you can thoroughly plan the details to ensure the overall system
requirements are accomplished. To assist you in planning and designing your
installation, review the basic system diagram shown in Figure 2-1.
WARNING: The AGS is not an ignition-protection rated device and
should not be installed in any location that requires ignition-protected
equipment. To prevent fi re or explosion, do not install the AGS module
in any area with extremely fl ammable liquids like gasoline or pro-
pane, or in an area that contains connections between components
of a fuel system.
CAUTION: Installations should be performed by qualifi ed personnel,
such as a licensed or certifi ed electrician. It is the installer’s respon-
sibility to determine which safety codes apply and to ensure that all
applicable installation requirements are followed. Applicable installa-
tion codes vary depending on the specifi c location and application.
CAUTION: Review the “Important Safety Instructions” in the front
of this manual before any installation.
2.1 Installation Requirements
Review the following requirements prior to performing the installation:
•
For the AGS to automatically start and stop the generator properly, the
generator must include an electric start and an automatic choke. To pre-
vent generator damage and to ensure reliable operation, use generator
models designed for unattended operation. These models should also be
equipped with remote operation connections and have protective systems
that shut down the generator when low oil pressure, over-temperature,
starter lockout, or over-crank conditions occur.
• T he AGS is connected to a Magnum inverter by a 10-foot communications
cable. Before installing the AGS and connecting any wires, fi rst determine:
1) the communications cable route throughout the home or vehicle/boat
from the AGS module to the inverter, 2) the start/stop signal wire route
from the AGS module to the generator, and 3) the wire route from the
AGS module to the monitored battery bank.
• Always check for existing electrical, plumbing, or other areas of potential
damage BEFORE drilling or cutting into walls.
• If installing the AGS in a boat, RV or truck, ensure the conductors pass-
ing through walls, bulkheads, or other structural members are protected
to minimize insulation damage such as chafi ng, which can be caused by
vibration or constant rubbing.
• Do not mount the AGS module in a closed battery compartment or in
an area where water (any liquid) can enter the AGS and cause shorting
or corrosion.
• The AGS, if possible, should be wired so as not to interfere with the
manual start/stop switches on your generator, or with your air conditioner
controls if the high temp start feature is used to power the air conditioner.
