10.0 Using the ME-RTR Router
10.3.2.2 ME-RTR Router’s PORT Button
The router’s PORT button provides you a way to access the AGS Home
screen. The AGS Home screen displays the generator’s current status, run
time setting, DC stop voltage, temperature, and the router port number to
which the AGS is connected. From the router’s System Home screen (press
and hold the METER button 3 seconds to access), continue to press the PORT
button until the AGS Home screen displays.
10.3.2.3 ME-RTR Router’s TECH Button
From the AGS Home screen (see Section 10.3.2.2), press the ME-RTR’s
TECH button, and then rotate the SELECT knob to access:
TECH: 01A INV AGS Temp Sensor
This menu displays the temperature of the area surrounding the remote
temp sensor (temperature listed next to router port# in which sensor is
connected). If the remote temp sensor is not installed, “TS Open” displays.
TECH: 02 Firmware Versions
This menu displays the software/fi rmware version of all the devices con-
nected directly to the ports of the router (P1-P6). If an AGS is connected, the
screen alternates the “AGS” display with the revision of the connected AGS.
METER: 03D AGS Temp Menu
The read-only menu displays the temperature of the AGS remote tempera-
ture sensor (included with AGS, but use is optional), and is helpful in deter-
mining its proper placement and operation. This temperature value can be
displayed in either Fahrenheit (default setting) or Celsius.
Info: Use the SETUP: 01E Temp Display menu to change the tem-
perature format, if required.
METER: 03E Since Gen Run (Days) Menu
This read-only menu displays the number of days since the generator has
last run. This is useful in determining if the start and stop settings are set
up correctly. This timer begins once the CTRL: 03 Gen Control menu is set
to AUTO, and then counts by 1 for every 24-hour period the generator does
not start. The Days Since Run timer resets any time the generator starts,
which could be either by autostarting the generator (including from a previ-
ous exercise run), or manually starting the generator.
Info: When the DIP switch inside the AGS is set to “2-Wire Standby
Mode”, if you do not use the ME-RTR to manually turn the generator
on, the Days Since Run timer will not be reset to zero.
Info: This display is used by the SETUP: 04F Max Gen Run Time
menu to determine the generator’s maximum run time when start-
ed automatically.
