Casio DT-X30 - Manual (Page 18)

E-16
4 Screen Displays text and operating instructions. In addition, operations
can be performed and data can be input using the stylus
provided.
5 Microphone Used for audio input (including voice).
6 Power Key Turns the power on and off.
7 CLR Key Used to clear one letter to the left of the cursor.
8 Center Trigger Key Used to perform bar code reading. Can be assigned an arbitrary
function.
9 Enter Key Press when fi nishing entering numerical values or when moving
to the next step.
10 Cursor Keys Perform the same functions as the up and down arrow keys on a
PC keyboard.
11 Numeric Keys Used to enter numeric values and decimal points.
12 Fn Key Used to make various settings in combination with the function
keys or numeric keys or when starting a pre-registered
application.
13 Function Keys
(Windows CE
models) Various functions other than bar code reading can be assigned to
these keys.
The default key assignments are as follows.
F1: Clears one letter to the left of the cursor.
F2: Not assigned.
F3: Not assigned.
F4: Enters a “-” (minus symbol).
F5: Enters a space.
F6: Not assigned.
F7: Not assigned.
F8: Selects text entry mode.
(The mode changes in order of Numeric
➝ Uppercase letter ➝
Lowercase letter.)
Function Keys
(Windows Mobile
models) Various functions other than bar code reading can be assigned to
these keys.
The default key assignments are as follows.
F1: Left soft key.
F2: Right soft key.
F3: Not assigned.
F4: Not assigned.
F5: Not assigned.
F6: Raises sound volume.
