Items supplied
FGW 84 A1
GB
MT
Items supplied
1 x Barbecue skewer (incl. 2 x barbecue racks and 1 x wooden handle)
2
1 x Wind protector, left
3
1 x Wind protector, middle
4
1 x Wind protector, right
5
1 x Grill grate (including 2 handles)
6
1 x Firebowl
7
1 x Handle
8
2 x Handle holder, short
9
2 x Stand braces
10
2 x Cross braces
11
5 x Storage slats, long
12
2 x Wheels
13
1 x Axle
14
2 x Wheel brace
15
2 x Storage holder, long
16
2 x Reinforcing braces
17
3 x Storage slats, short
Connection elements
M5x10
25x
M5x12
22x
Ø4x10
2x
M5
47x
M8
2x
Ø5.4
47x
M4x10
2x
Assembly
Preparing for assembly
Allow yourself plenty of time for the assembly of the trolley barbecue. Secure a
level workplace of about two to three square meters. Remove all individual items
from the packaging and place them where they are conveniently handy. Check
the items to ensure that that they are all present and without any damage.
