25 GB
Safety information / Installation
Safety information
DANGER TO
LIFE AND RISK OF ACCIDENTS
FOR INFANTS AND CHILDREN!
Never leave children unattended with the pack-
aging material. Suffocation hazard. Keep this
product well away from children. This product
is not a toy.
BEWARE OF ELECTRIC SHOCK!
Leaking or water discharge can
lead to life-threatening danger due
to electric shock. Carefully check that all con-
nections are watertight. Also ensure that all
wires of electric appliances are correct and
have been securely installed.
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts
are correctly assembled. Incorrect assembly
could lead to injury. Please note that washers
and gaskets are wear parts and therefore will
need to be replaced from time to time. Dam-
aged parts could impact safety and function.
Be sure all seals are correctly seated.
SCALDING RISK! When adjusting the hot
water temperature be sure the water tempera-
ture is not too high.
CAUTION! Be careful not to reverse the hot/
cold water plaque 2 . The correct position is:
left = red (hot water),
right = blue (cold water).
CAUTION! DAMAGE TO THE ARTICLE!
Please have all installations performed by
skilled individuals.
Please note that the seals are wear parts and
must be changed from time to time.
Any leakage or sudden escape of water can
cause considerable damage to buildings and
property. All connections must therefore be
checked carefully to ensure that they are tight.
Familiarise yourself prior to installation with all
local conditions, e.g. water connections and
shut-off device.
The product is only suitable for use in rooms in
which a temperature above 0 is maintained.
Installation
Note: Familiarise yourself with the product prior to
assembly. Carefully read the following assembly in-
structions and safety advice. In the event of incor-
rect installation, all warranty claims – particularly
in relation to subsequent damage – are excluded.
CAUTION! Before you start installation turn
off the water supply at the mains. Otherwise
injuries and/or property damage may occur.
Connecting the fitting
Note: this step requires an SW 30 mm open-end
spanner and sealing tape.
Note: cover any parts which will be screwed with
a damp cloth or plastic clamps. This will prevent
scratches.
Follow these steps:
Wrap sealing tape around the roughened
threaded part (½“ thread) of the S-connectors
16 .
Note: sealing tape not included.
Screw the S-connectors 16 with the sealed
threaded parts into the wall connectors.
Horizontally align the screwed in S-connectors
16 with the spacing guide for the fitting.
By hand, tightly screw the caps 15 onto the
S - connectors 16 to the wall.
Insert the seals 14 into the swivel nuts 11 and
screw the fitting body 10 with the swivel nuts
11 onto the S-connectors 16 .
Connecting accessories (shower
hose and shower head)
Note: Shower hose and shower head are not
included in delivery.
Note: cover any parts which will be screwed with
a damp cloth or plastic clamps. This will prevent
scratches.
Connect a standard shower hose to the shower
connector 9 .
