8 GB
Preparation / Before installation / Preparations for use
– Cable H03VV-2F of the required length with wire
end ferrules (minimum cross-section 2 x 0.75 mm 2 )
– Pencil / Marking tool
– Voltage tester
– Screwdriver
– Electric drill
– Hole cutter
– Edge cutter
– Ladder
Q Before installation
Important: The electrical connection must be
carried out by a qualified electrician or someone
trained to perform electrical installations. This person
must be familiar with the features of the light and
the connection requirements.
j Familiarise yourself with all instructions and
diagrams in this manual as well as with the
light before installation.
j Before installation, ensure that the cable that
the light is to be attached to is not live. Remove
its fuse or switch off the automatic cutout in the
fuse box (0 position, see Fig. A).
j Use the voltage tester to check that there is no
voltage.
Q Preparations for use
Q Installation
j Mark the positions of the installation spotlights.
Use the hole cutter (ø 68 mm) to drill the 6 holes
at the installation point (see Fig. B). Please take
into account the distance between two installa-
tion spotlights. This must be at least 20 cm.
j Guide the power line through the installation
opening (see Fig. C).
j Insert the retaining springs 4 into the spotlights
(see Fig. E and F). The small lug of the retaining
springs
4 must lie on the inside of the housing
of the lamp 1 so that the retaining springs 4
can receive the electric current.
j Open the mains socket 8 by unscrewing the
cover 5 with a screwdriver (see Fig. G).
j Release the cable holder 7 using a screwdriver.
j Connect the power line to the terminal block 6
(see Fig. G) and tighten the cable holder 7
with a screwdriver. Pay attention to the L / N
marking (L = black or brown, N = blue) of the
connected wires. Any green / yellow wire pre-
sent is not connected, no earth connection, as
the lamp belongs to protection class II. Use a
cable of type H03VV-2F with a minimum cross-
section of 2 x 0.75 mm² and wire end ferrules.
j Seal the mains socket 8 again by tightening
the cover 5 with a screwdriver.
j Fit the mains connection box 8 back into the
installation opening.
j Pull the socket 9 with its connection cable out
of each opening.
j Place the fitting 9 of the mains socket 8 on
the bulb 2 including the lamp housing 1
and turn the bulb 2 with a ¼ turn in a clock-
wise direction until it is tight (see Fig. H).
j Before using the downlight spots remove any
insulation from around the area of the mains
connection box
8 and the downlight spots
(see Fig. I).
j Fold the two retaining springs 4 upwards and
guide the installation spotlights with the con-
nection cable into the installation opening (see
Fig. J). After you have pushed the spotlight into
the opening, unfold the retaining springs
4
use them to fix the installation spotlight in place
(see Fig. K). Proceed in the same way with the
five other installation spotlights.
j The downlights are now ready for use.
j Now switch on the power supply (see Fig. L).
Q Changing the bulbs
CAUTION! DANgeR OF eLeCTRIC
SHOCK! When changing the bulbs,
first disconnect the light from the mains
supply. Remove its fuse or switch off the automatic
cutout in the fuse box (0 position).
