Correct procedure
Check before fastening the light to the ceiling
whether the ceiling is suitable for supporting
the light. If necessary seek advice from your
local DIY supplier or a construction professional.
Examine the ceiling before installation and
choose suitable installation fixings.
For ceiling installation we have supplied fixings
suitable for ordinary solid concrete or masonry
construction.
Replace defective bulbs with new ones imme-
diately, otherwise damage to the product may
occur.
Only use 230 V ∼ halogen light bulbs with a
GU 10 base and a maximum output of 40 watts.
Fit the light in such a way to ensure it is protected
from damp and dirt.
Preparation
Required tools and materials
The tools and materials mentioned are not included
in the delivery. The details and values given are non-
binding and for guidance only. The nature of the mate-
rial depends on the individual circumstances on site.
– Pencil / Marking tool
– Voltage tester
– Crossed screwdriver
– Electric drill
– Drill
– Edge cutter
– Ladder
– Hammer
Before installation
Important: The electrical connection must be made
by a qualified electrician or a person authorised
to perform electrical installations. This person must
be familiar with the properties of the light and all
connection regulations.
Before installation, please familiarise yourself
with the instructions and illustrations in this
operating manual and with the light itself.
Make sure before installation that there is no
voltage on the line you will be connecting the
light to. To do this, remove the fuse or switch off
the circuit breaker in the fuse box (0 position).
Check that there is no voltage using a voltage
tester.
Installation
Note: You will need an electric drill to install the light.
CAUTION! RISK OF INJURY! Please read
the operating instructions for your drill.
Remove the screws on the side of the
connection enclosure.
Remove the mounting stirrup from the
connection enclosure.
Mark the positions for the drilled holes on the
ceiling using the predrilled holes in the mounting
stirrup as a guide.
Now drill the fixing holes.
CAUTION! Ensure that you do not damage
any cables in the ceiling.
Insert the dowels into the drilled holes.
Fix the mounting stirrup to the ceiling with the
screws.
Now connect the connection cable of the light
to the mains connection cable (external) by
means of the terminal block.
Note: Ensure that each wire of the mains
connection cable (external) is properly con-
nected in the correct place: live wire, black or
brown = symbol L, neutral wire, blue = symbol N,
protective earth wire, green-yellow = symbol .
Fix the light to the mounting stirrup with the
screws.
Note: Use a clean, fluff-free cloth when you
are inserting a bulb.
Use a suction cup to insert the bulb and turn it
a ¼ turn clockwise. Check that it is correctly
seated.
Your light is now ready for operation.
