Livarno Z30802A-BS / Z30802B-BS - Manual (Page 26)

24 GB/MT
Safety Information / Preparation / Preparations for use
rISK OF InJUrY FrOM BUrnS! Ensure
the lamp has been switched off and allowed to
cool before you touch it. In this way you will
avoid the danger of burns. Light bulbs develop
a great deal of heat.
J Do not touch bulb components or bulbs as they
can reach temperatures higher than 90 °C
during operation.
J Allow the light to cool down completely before
replacing a defective bulb.
J Replace defective bulbs immediately. Before
replacing the bulb always remove the mains
plug from the socket.
J If a protective glass cover breaks have it replaced
immediately at the service centre or by an elec-
trician.
J Do not operate this light with a dimmer or an
electronic switch. It is not suitable for this mode
of operation.
J FIrE HAZArD! Fit the light so
that it is at least 0.2 m away from
the material illuminated. Fire can
result from the development of too much heat.
J Never leave the light operating unattended.
J Do not allow any objects to cover the light. Fire
can result from the development of too much heat.
J Do not allow the lamp or the packaging materials
to lie around unattended. Plastic film or bags,
Styrofoam etc. can turn into dangerous toys for
children.
Working safely
J Use a 230 volt ~ T5 fluorescent tube type bulb
with a maximum power output of 13 watt.
J Fit the light in such a way to ensure it is
protected from damp and dirt.
J Make careful preparations for the assembly
and take sufficient time. Clearly lay out all com-
ponents and any additional tools or materials
that might be required so that they are readily to
hand.
J Remain alert at all times and always watch
what you are doing. Always proceed with
caution and do not assemble the lamp if you
cannot concentrate or feel unwell.
Q Preparation
Q required tools and materials
The tools and materials mentioned are not included
in the delivery. The details and values given are
non-binding and for guidance only. The nature of
the material depends on the individual circumstanc-
es on site.
- Pencil / Marking tool
- Screwdriver
- Electric drill
- Drill bit
- Spirit level
Q Preparations for use
Q Mounting the light
1. Measure up the wall or mounting surface for
drilling the holes. Use a spirit level to improve
accuracy.
2. Mark the two mounting holes a distance of
approx. 41 cm apart.
3.
sure that you do not damage any electrical
cables during this operation.
4. Insert the supplied dowels into the drilled holes.
Insert the supplied screws into the dowels and
tighten them.
5. Attach the light using the appropriate mounting
holes 4 or 8 to the screws.
6. Insert the light connector plug of the power supply
cable 12 into the light connector socket 1 .
7. Insert the mains plug of the power supply
cable 12 into a convenient mains socket. Your
light is now ready for operation.
Q Connecting several
lights together
CAUtIOn! Make sure that all under-cabinet lights
are linked together by means of the connecting
