32 GB
… / Mounting / Changing … / Maintenance and Cleaning / Guarantee and Service
Familiarise yourself with all instructions and
diagrams in this manual, as well as with the
luminaire before installation.
Before installation, ensure that the cable that the
luminaire will be attached to is de-energised.
To do this, remove the fuse or switch off the
circuit breaker in the fuse box (0 position).
Use the voltage tester to verify de-energised
status.
Mounting
Remove the visible screws 5 on the side of the
connection housing 6 and take off the mount-
ing bracket 4 on the rear (see fig.).
Use the slotted holes intended for the mounting
bracket 4 to mark the bores.
Drill the fastening bores (∅ approx. 6 mm, depth
approx. 40 mm). Ensure that you do not damage
the supply line.
Introduce the dowels 7 into the bores. Fasten
the mounting bracket 4 with the provided
screws 8 .
Now connect the connection cable of the lumi-
naire to the mains connection cable 10 via the
terminal block 9 , (see fig.).
Also ensure that the coloured lines are connected
together.
Connect the protective conductor (green-yellow)
to the earth terminal marked in the connection
housing
6 (see Fig.).
Use the screws 5 to fasten the luminaire to
the mounting bracket 4 .
Use a clean, lint-free cloth to insert a bulb 2 .
Push the bulb 2 carefully into the socket.
Check for correct fitting.
Screw the lamp lens
1 onto the spotlight
head 3 in a clockwise direction.
Your luminaire is now ready for operation.
Changing the bulb
CAUTION! DANGER OF ELECTRIC SHOCK!
To replace the bulb, first disconnect the luminaire
from the mains circuit. To do this, remove the fuse
or switch off the circuit breaker in the fuse box
(0 position).
CAUTION! DANGER OF BURN INJURIES!
Allow the luminaire to cool completely.
Replace the bulb 2 only after it has fully cooled.
Turn the lamp lens 1 from the spotlight head 3
in an anticlockwise direction.
Remove the defective bulb 2 carefully out of
the socket.
Use a clean, lint-free cloth to replace a bulb.
Only use 220-240 V ∼ eco halogen light bulbs
with a G9 base and a maximum of 28 Watts.
Insert the new bulb 2 into the socket. Check
that it sits correctly.
Screw the lamp lens 1 onto the spotlight
head 3 by tightening in a clockwise direction.
Maintenance and Cleaning
CAUTION! DANGER OF ELECTRIC SHOCK!
To clean the luminaire, first disconnect it from the
mains circuit. To do this, remove the fuse or switch
off the circuit breaker in the fuse box (0 position).
CAUTION! DANGER OF ELECTRIC SHOCK!
For electrical safety reasons, never clean the lumi-
naire with water or other fluids nor immerse it in
water.
CAUTION! DANGER OF BURN INJURIES!
Allow the luminaire to cool completely.
Do not use solvents, benzene or similar sub-
stances. They could damage the luminaire.
Only use a dry, lint-free cloth for cleaning.
Guarantee and Service
Warranty Declaration
This product has a 3 year guarantee from the date
of purchase extended only to the original buyer,
not transferable. Please keep your receipt as proof
of purchase. The guarantee applies to material or
manufacturing defects only. It does not cover wear
