Model PD6300 Pulse Input Rate/Totalizer
Instruction Manual
33
Display Parameter
Action/Setting
Description
off
Fail-safe off
Disable fail-safe operation
DeLAY
Delay
Enter relay Time Delay menu
DLY 1
Delay 1
Enter relay 1 time delay setup
On 1
On
Set relay 1 On time delay
OFF 1
Off
Set relay 1 Off time delay
Aout
Analog output
Enter the Analog output scaling menu
Dis 1
Display 1
Program display 1 value
Out 1
Output 1
Program output 1 value (e.g. 4.000 mA)
Dis 2
Display 2
Program display 2 value
Out 2
Output 2
Program output 2 value (e.g. 20.000 mA)
prog
Program
Enter the Program menu
factor
K-factor
Scaling
Programs unit to convert input pulse to
rate in engineering units
sCalE
Scale
Enter the Scale menu
Cal
Calibrate
Enter the Calibrate menu
Inp 1
Input 1
Calibrate input 1 signal or program input 1
value
Dis 1
Display 1
Program display 1 value
Inp 2
Input 2
Calibrate input 2 signal or program input 2
value (up to 32 points)
Dis 2
Display 2
Program display 2 value (up to 32 points)
Error
Error
Error, calibration not successful, check
signal or programmed value
T tb
Total time
base
Program total time base
T CF
Total conver-
sion factor
Program total conversion factor
