17
Index Data type MEASUREMENTS UNIT
1 Unsigned16 UPS states (see the STATES table) Flag
2 Unsigned16 UPS states (see the STATES table) Flag
3 ÷11
12 Unsigned16 Input mains star voltage V1 V
13 Unsigned16 Input mains star voltage V2 V
14 Unsigned16 Input mains star voltage V3 V
15 Unsigned16 Input current phase L1 0.1*A
16 Unsigned16 Input current phase L2 0.1*A
17 Unsigned16 Input current phase L3 0.1*A
18 Unsigned16 Input frequency 0.1*Hz
19 ÷21
22 Unsigned16 Bypass mains star voltage V1 V
23 Unsigned16 Bypass mains star voltage V2 V
24 Unsigned16 Bypass mains star voltage V3 V
25 Unsigned16 Bypass frequency 0.1*Hz
26 Unsigned16 Output star voltage V1 V
27 Unsigned16 Output star voltage V2 V
28 Unsigned16 Output star voltage V3 V
29 ÷31
32 Unsigned16 Output current phase L1 0.1*A
33 Unsigned16 Output current phase L2 0.1*A
34 Unsigned16 Output current phase L3 0.1*A
35 Unsigned16 Output peak current phase L1 0.1*A
36 Unsigned16 Output peak current phase L2 0.1*A
37 Unsigned16 Output peak current phase L3 0.1*A
38 Unsigned16 Load phase L1 %
39 Unsigned16 Load phase L2 %
40 Unsigned16 Load phase L3 %
41 ÷43
44 Unsigned16 Output frequency 0.1*Hz
45 ÷47
48 Unsigned16 Battery voltage 0.1*V
49 ÷50
51 Unsigned16 Battery current 0.1*A
52 Unsigned16 Remaining Battery Capacity %
53
54 Unsigned16 Remaining back-up time Minutes
55 ÷61
62 Unsigned16 Internal UPS temperature °C
63 Unsigned16 Sensor 1 temperature °C
64 Unsigned16 Sensor 2 temperature °C
65 ч72
