RLX-OPC-SRV ♦ ProSoft Software Start Here
RadioLinx® OPC Server for Frequency Hopping and Industrial Hotspot™ Radios
Page 8 of 108 ProSoft Technology, Inc.
January 22, 2009
1.2.2 RadioLinx Frequency Hopping Radios
ƒ RLX-FHS
ƒ RLX-FHE
ƒ RLX-FHES
Tag Name Contracted name Data Type
RSSI RSSI Integer
Signal-to-Noise Ration SignalToNoise Integer
Associations Associations Integer
Bit error Rate BitErrRate Floating Point
Reset Statistics* Reset_stats Integer
Serial Number SerialNum String
Parent Address ParentAdd Integer
Total Bytes Forward TotBytFwd Integer
Total Bytes Reverse TotBytRev Integer
TX Packet Errors TxPackErrs Integer
Total Good Packets TotGoodPacks Integer
* Are also write tags. TX = Transmitted
1.2.3 RLX-IFHE
Tag Name Description
RSSI Receive Signal Strength Indicator measurement.
Unit Description Radio name
IP Address The IP Address of the current radio.
Unit Address: The unit address is, and must be, a unique identifier of each modem in
a network.
VALUES
1 Master
65535 Broadcast
Retransmissions This register determines the maximum amount of times that a packet
will be retransmitted (in addition to the initial transmission).
VALUES
0-255
Destination Address This register specifies the ultimate destination for the data.
VALUES
1-65535
Roaming This feature allows a Remote unit to synchronize with a specified
‘upstream’ unit (either Master or Repeater).
VALUES:
65535 full roaming
1-254 specific (fixed) unit address (Master or Repeater)
with which to associate
Serial Number Serial number of radio (RF) module.
Version Firmware version within radio module.
