Xiaomi Mi Vacuum Cleaner G9 - Manual (Page 5)

6 7
Installing the Accessories onto the Vacuum Cleaner
How to Install
Insert until it clicks into place Insert until it clicks into place
Note: Mini electric brush should not be used with the extension rod.
Installing the 2-in-1 Charging & Storage Mount
1. The 2-in-1 charging & storage mount should be installed in a
cool, dry place with an electrical outlet nearby. Prior to installing,
ensure that there are not any wires or pipes in the space directly
behind where the mount will be installed.
2. The bottom of the mounting template sticker should be level
and at least 1.03 m from the ground, and its top should have at
least 30 cm of clearance above it.
* The replaceable battery is not included and purchased separately.
Extended Dock Charging Plate
Extended Dock
You can simultaneously charge the replaceable
battery* when charging the vacuum cleaner on the
2-in-1 charging & storage mount.
3. Use a power drill with an 8 mm drill bit to drill a hole into each
hole marker on the mounting template sticker, then insert a wall
plug into each hole.
4. Align the mounting holes on the 2-in-1 charging & storage mount
to the holes on the wall, then attach the mount to the wall using
the included screws.
Mounting Template
Sticker
Screw Wall Plug
Recommended Height: At least 1.03 meters from the ground
1.03 m
30 cm
