Xiaomi Mi Vacuum Cleaner G9 - Manual (Page 9)

14 15
1. Insert the cyclone assembly vertically into the dust
compartment, and make sure that the handle of the cyclone
assembly line up with the slot on the left side of the dust
compartment. Turn the handle clockwise until it locks, then flip
the handle down. 3. Slightly tilt the dust compartment so its slot aligns with the clip
on the vacuum cleaner. Then gently push the dust compartment
until it clicks into place.
2. Place the pre-filter with its front side facing up into the cyclone
assembly.
Installing the Dust Compartment, Pre-filter, and
Cyclone Assembly
1
2
Insert until
it clicks into
place
2. Remove the HEPA filter from the vacuum cleaner by pulling it
down in the direction shown in the figure. Cleaning the HEPA Filter
1. Remove the dust compartment as shown in the figure.
Note: It is recommended to clean the HEPA filter once every 4
to 6 months.
3. Clean the HEPA filter with clean water. Make sure you rotate the
HEPA filter 360° to thoroughly remove all dust caught in the filter.
Lightly tap the filter several times to remove any excess dirt.
Notes:
Only use clean water to clean the filter. Do not use detergent.
Do not attempt to clean the HEPA filter with a brush or finger.
Care & Maintenance
2
1 Pre-filter
1
2
Dust Compartment Release Switch
