50
Appendices
Key
The transition starts at light areas or dark areas.
204
Key01 The dark part of the A-Bus picture transitions to the light part of the B-Bus picture.
205
Key02 The light part of the A-Bus picture transitions to the dark part of the B-Bus picture.
206
Key03 The light part of the B-Bus picture transitions to the dark part of the A-Bus picture.
207
Key04 The dark part of the B-Bus picture transitions to the light part of the A-Bus picture.
fig.key-icons.eps
204 : Key01
205 : Key02
206 : Key03
207 : Key04
