3-6
Chapter 3: General Instruction
DisplayPort
HDMI
Auto Input Detection
USB-C
MOVE/ENTER
BACK
EXIT
Input Select
System Setup
MyFavorite
Color
Gaming
Racing Mode
ROG Strix XG49WCR HDR OFF
DisplayPort 3840x2160 165Hz
PIP/PBP Setup
5. PIP/PBP Setup
The PIP/PBP Setting allows you to open up sub-window(s) connected
from any video source.
MOVE/ENTER
BACK
PIP/PBP Mode
Color setting
PIP Size
PIP/PBP Source
EXIT
Input Select
System Setup
MyFavorite
Color
Gaming
PIP/PBP Setup
Racing Mode
ROG Strix XG49WCR HDR OFF
DisplayPort 3840x2160 165Hz
• PIP/PBP Mode
: Select PIP, PBP or turn it off.
• PIP/PBP Source
: Selects the video input source among,
“USB-C,DisplayPort, HDMI.
• Color setting
: Set GameVisual mode for each PIP/PBP window.
• PIP Size
: Adjust the PIP size to “Small”, “Middle”, or “Large”.
• Disable Variable Refresh Rate and HDR function to enable
PIP/PBP function.
