HP M24 23.8" Webcam Monitor - Manual (Page 31)

60.4 cm (23.8 in) model specifications
This section provides specifications for your monitor.
Table A-2 Technical specifications
Specification Measurement
Display, wide-screen 60.4 cm 23.8 in
Type IPS
Viewable image size 60.4 cm diagonal 23.8 in diagonal
Maximum weight (unpacked) 6.3 kg 13.86 lbs
Dimensions (include base)
Height (highest position) 52.34 cm 20.61 in
Height (lowest position) 42.34 cm 16.67 in
Depth 21.14 cm 8.32 in
Width 53.95 cm 21.24 in
Tilt –5° to 23°
Swivel ± 45°
Environmental requirements temperature
Operating temperature 5°C to 35°C 41°F to 95°F
Storage temperature –20°C to 60°C –4°F to 140°F
Storage humidity 5% to 95% (noncondensing)
Power source 100 V ac to 240 V ac 50/60 Hz
Input terminal One HDMI port, one DisplayPort connector, and one USB Type-C DisplayPort
connector
Preset display resolutions
The following display resolutions are the most commonly used modes and are set as factory defaults. This
monitor automatically recognizes these preset modes, and they will appear properly sized and centered on
the screen.
Table A-3 Preset display resolutions
Preset Pixel format Horz freq (kHz) Vert freq (Hz)
1 640 Ч 480 60.0 60.000
2 720 Ч 400 70.0 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 31.469 60.000
5 1280 Ч 720 45.000 60.000
6 1280 Ч 800 49.702 60.000
26 Appendix A Technical specifications
