QuickSpecs
HP Elite Series 800 G9 Desktops PCs
Technical Specifications – Miscellaneous Features
Not all configuration components are available in all regions/countries.
c08017769 – DA 17000 – Worldwide – Version 22 – August 21, 2022
Page 103
MISCELLANEOUS FEATURES
Management Features
• Advanced Configuration and Power Management Interface (ACPI). Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and peripherals in a low-power or
powered-off state without affecting other elements of the system.
• Intel® Wired for Management support; industry wide initiative to make Intel® architecture based PCs, servers and mobile
computers more inherently manageable out-of-the-box and over the network
• Dual State Power Button; acts as both an on/off button and a suspend-to-sleep button
Serviceability Features
• Dual colored power LED on front of computer to indicate either normal or fault condition
• Diagnostic LED Explanation Table:
o Power LED will blink red 2 to 5 times, then blink white 2 or more times, then repeat (with beep tones for each blink
initially):
▪ 2 red + 2 white User must provide file for BIOS recovery (USB storage typically)
▪ 2 red + 3 white User must enter a key sequence to proceed with recovery by policy
▪ 2 red + 4 white BIOS recovery is in progress
▪ 3 red + 2 white Memory could not be initialized
▪ 3 red + 3 white Graphics adaptor could not be found
▪ 3 red + 4 white Power supply failure / not connected
▪ 3 red + 5 white Processor not installed
▪ 3 red + 6 white Current processor does not support an enabled feature
▪ 4 red + 2 white Processor has exceeded its temperature threshold / system thermal shutdown
▪ 4 red + 3 white System internal temperature has exceeded its threshold
▪ 5 red + 2 white System controller firmware is not valid
▪ 5 red + 3 white System controller detected BIOS is not executing
▪ 5 red + 4 white BIOS could not complete initialization / PCA failure
▪ 5 red + 5 white System controller rebooted the system after a health or recovery timer triggered
• HP PC Hardware Diagnostics UEFI:
o This utility enables hardware level testing outside the operating system on many components. The diagnostics
can be invoked by pressing F2 at POST, and is available as a download from HP Support
• System/Emergency ROM
• Flash ROM
• CMOS Battery Holder for easy replacement
• 1 Aux Power LED on System PCA
• Processor ZIF Socket for easy Upgrade
• Over-Temp Warning on Screen (Requires IM Agents)
• DIMM Connectors for easy Upgrade
• Clear CMOS Button
• NIC LEDs (integrated) (Green & Amber)
• Dual Color Power and HD LED - To Indicate Normal Operations and Fault Conditions
• Color coordinated cables and connectors
• Tool-less Hood Removal
• Front power switch
• System memory can be upgraded without removing the system board or any internal components
• Tool-less Hard Drive, CD & Diskette Removal (For MT, SFF, and DM only)
• Green Pull Tabs, and Quick Release Latches for easy Identification
