QuickSpecs
HP Elite Series 800 G9 Desktops PCs
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c08017769 – DA 17000 – Worldwide – Version 22 – August 21, 2022
Page 70
Realtek RTL8852BE 802.11ax 2x2 Wi-Fi + BT5.2 (802.11ax 2x2, supporting gigabit data rate) 1
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability Wi-Fi certified modules
Frequency Band 802.11b/g/n/ax
• 2.402 – 2.482 GHz
802.11a/n/ac/ax
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates • 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: max 300Mbps
• 802.11ac: max 866.7Mbps
• 802.11ax: max 1201Mbps
Modulation Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM
Security 2 • IEEE and WiFi certified 64 / 128 bit WEP encryption for a/b/g mode only
• AES -CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA -PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certifi cation
• WPA3 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power 3 • 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ax HE40(2.4GHz): +10dBm minimum
• 802.11ax HE80(5GHz): +10dBm minimum
Power Consumption • Transmit mode:2.5 W
• Receive mode:2 W
