14
Preparations
Depending on the speakers you connect, you may need to
change the speaker impedance setting on this unit. Refer to
the page describing speaker connection (
 p9) and do the
following procedures if the change is required.
1. Press SETUP on the remote controller.
2. Press
D / C on the remote controller several times so
that input source indicators on the unit, such as "LINE 1"
and "LINE 2", start blinking.
0 The indicators blink and the current setting is
displayed.
3. Press B / A on the remote controller to change the
setting.
- 4 ≠ : "LINE 1" and "LINE 2" indicators are blinking
- 8 ≠ (default value): "LINE 1", "LINE 2", "LINE 3" and
"LINE 4" indicators are blinking
4. To exit the settings, press SETUP.
0 The setting mode ends after 5 seconds elapse with no
operations performed.
Speaker impedance settings
8Ω
4Ω
3
1
2
SETUP
/ / /
(BLINKING)
