2-6

Chapter 2: Basic Installation

Chapter 2

2.1.4

M.2 installation

•

The M.2 rubber pad is

optional for when installing

a single sided M.2 storage

device. Ensure to install the

bundled M.2 rubber pad

before installing your single

sided M.2 storage device.

•

DO NOT install the bundled

M.2 rubber pads when

installing a double-sided

M.2 storage device. The

rubber pad installed by

default is compatible with

double sided M.2 storage

devices.

1

1

2

OPTIONAL

3

4

5

4
