ROG STRIX B550-A GAMING

2-11

Chapter 2

2.1.8

Front I/O connector

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.2 Gen 1

To install USB 3.2 Gen 1 connector

This connector will only fit in one orientation. Push the connector until it clicks into place.

To install front panel connector
