3/4 USER’S GUIDE
Continued on the back 
OFF/ON OFF/ON OFF/ON OFF/ON
OFF/ON OFF/ON OFF/ON OFF/ON − + − + OFF/ON − + − + − + − + − + − + − +
− +
− + − +
OFF/ON
OFF/ON
(C1) (C2) (C3) (C4) (C5) (C6) (C7) (C8)
Keyboard Keys Used for Configuring Settings
* 1: PX-770
* 2: PX-870
Format USB Flash Drive * 2
Delete USB Flash Drive * 2
Local Control
Speaker Out * 2
Volume Sync Equalizer (Off, Weak, Normal, Strong) * 2
Hall Simulator (DUTCH CHURCH) * 2 /Reverb (1) * 1
Hall Simulator (FRENCH CATHEDRAL) * 2 /Reverb (4) * 1
Lower Pedal
String Resonance (1 to 4) * 2
Key-on Action Noise * 2
CONCERT PLAY LESSON
CONCERT PLAY SELECT (Song)
CONCERT PLAY VOLUME
METRONOME TEMPO
METRONOME BEAT
Select Music Library Song/
Select Tempo, Beat, Temperament Tone
Select Layer Tone
Temperament Type
Temperament Key Note
Keyboard Touch (Off, 1 to 3)
Brilliance (–3 to 0 to +3)
Transpose (–12 to 0 to +12)
Layer Balance (–24 to 0 to +24)
A-tuning (415.5 to 440.0 to 465.9) Octave Shift (–2 to 0 to +2)
Keyboard Volume (0 to 42)
Music Library Song Volume (0 to 42)
Metronome Volume (0 to 42)
Audio Recorder Volume
(0 to 42) * 2
Operation Tone
USB Flash Drive Mode * 2
Save to USB Flash Drive * 2
Load from USB Flash Drive Mode * 2
USB Flash Drive Mode
(MIDI, Storage)
Send Channel (1 to 16)
Head Phone
Mode * 2
Hall Simulator (Off) * 2 /Reverb (Off) * 1
Hall Simulator (STANDARD HALL) * 2 /Reverb (2) * 1
Hall Simulator (BERLIN HALL) * 2 /Reverb (3) * 1
Chorus (Off, 1 to 4)
Damper Noise
Hammer Response (1 to 4) * 2
Lid Simulator (1 to 4) * 2
Key-off Action Noise * 2
CONCERT PLAY a (Song)
CONCERT PLAY LISTEN
CONCERT PLAY PLAY
Duet Mode (Off, On, Pan)
Auto Resume
Panel Lock
Piano Buttons
The FUNCTION button is used in combination with other
buttons and keys.
To change a setting, hold down the
FUNCTION button
as you press the button or key that is assigned the
setting you want to configure.
• When you press a key, the Digital Piano beeps to
indicate the current setting.
• A long beep indicates that a setting is turned off.
Using the FUNCTION Button
Tone List
Tone Name Program
Change
Bank
Select
MSB
GRAND PIANO CONCERT 0 0
GRAND PIANO MELLOW 1 0
GRAND PIANO BRIGHT 2 0
MODERN PIANO 3 0
ROCK PIANO 4 0
JAZZ PIANO 5 0
ELEC.PIANO 1 6 0
ELEC.PIANO 2 7 0
FM E.PIANO 8 0
60’S E.PIANO 9 0
HARPSICHORD 10 0
VIBRAPHONE 11 0
STRINGS 1 12 0
STRINGS 2 13 0
PIPE ORGAN 14 0
JAZZ ORGAN 15 0
ELEC.ORGAN 1 16 0
ELEC.ORGAN 2 17 0
BASS(LOWER) 18 0
Music Library List
Song No. Song Name
1 Nocturne Op.9-2
2 Fantaisie-Impromptu Op.66
3 Étude Op.10-3 “Chanson de l’adieu”
4 Étude Op.10-5 “Black Keys”
5 Étude Op.10-12 “Revolutionary”
6 Étude Op.25-9 “Butterflies”
7 Prélude Op.28-7
8 Valse Op.64-1 “Petit Chien”
9 Valse Op.64-2
10 Moments Musicaux 3
11 Impromptu Op.90-2
12 Marche Militaire 1 (Duet)
13 Frühlingslied [Lieder Ohne Worte Heft 5]
14 Fröhlicher Landmann [Album für die Jugend]
15 Von fremden Ländern und Menschen
[Kinderszenen]
16 Träumerei [Kinderszenen]
17 Tambourin
18 Menuet BWV Anh.114
[Clavierbüchlein der Anna Magdalena Bach]
19 Inventio 1 BWV 772
20 Inventio 8 BWV 779
21 Inventio 13 BWV 784
22 Praeludium 1 BWV 846 [Das Wohltemperierte
Klavier 1]
23 Le Coucou
24 Gavotte
25 Sonatina Op.36-1 1st Mov.
26 Sonatine Op.20-1 1st Mov.
27 Sonate K.545 1st Mov.
28 Sonate K.331 3rd Mov. “Turkish March”
29 Rondo K.485
30 Für Elise
31 Marcia alla Turca
32 Sonate Op.13 “Pathétique” 1st Mov.
33 Sonate Op.13 “Pathétique” 2nd Mov.
34 Sonate Op.13 “Pathétique” 3rd Mov.
35 Sonate Op.27-2 “Moonlight” 1st Mov.
36 Rhapsodie 2
37 Waltz Op.39-15 (Duet)
38 Liebesträume 3
39 Blumenlied
40 La Prière d’une Vierge
41 Csikos Post
42 Humoresque Op.101-7
43 Melodie [Lyrische Stücke Heft 2]
44 Sicilienne Op.78
45 Berceuse [Dolly] (Duet)
46 Arabesque 1
47 La Fille aux Cheveux de Lin [Préludes]
48 Passepied [Suite bergamasque]
49 Gymnopédie 1
50 Je Te Veux
51 Salut d’Amour
52 The Entertainer
53 Maple Leaf Rag
54 L’arabesque [25 Etüden Op.100]
55 La Styrienne [25 Etüden Op.100]
56 Ave Maria [25 Etüden Op.100]
57 Le retour [25 Etüden Op.100]
58 La chevaleresque [25 Etüden Op.100]
59 No.13 [Études de Mécanisme Op.849]
60 No.26 [Études de Mécanisme Op.849]
Concert Play List
Song No. Song Name
1 Je Te Veux
2 Vltava (Má vlast)
3 Canon
4 Tableaux d’Une Exposition “Promenade”
5 Piano Concerto No.20 K.466 2nd Mov.
6 Polovetzian Dance (Prince Igor)
7 Sonate K.331 1st Mov.
8 Violin Concerto 1st Mov.
9 Jesus, Bleibet Meine Freude
10 Melody In F
Song No. Song Name
Be sure to read and observe the following operating
precautions.
Location
Avoid the following locations for this product.
• Areas exposed to direct sunlight and high humidity
• Areas subjected to temperature extremes
• Near a radio, TV, video deck, or tuner
The above devices will not cause malfunction of the
product, but the product can cause interference in the
audio or video of a nearby device.
User Maintenance
• Never use benzine, alcohol, thinner, or other chemical
agents to clean the product.
• To clean the product or its keyboard, wipe with a soft
cloth moistened in a weak solution of water and a mild
neutral detergent. Wring all excess moisture from the
cloth before wiping.
Included and Optional Accessories
Use only accessories that are specified for use with this
product. Use of unauthorized accessories creates the risk of
fire, electric shock, and personal injury.
Digital Piano Finish
The finish of the Digital Piano has been designed to faithfully
reproduce the appearance of natural wood, including cuts
and other marks in the wood. Though knots, saw blade
marks, and/or other marks may be visible on the finish, they
are not actual cracks or scratches. Such marks will not
cause any problems with the use of your Digital Piano.
Weld Lines
Lines may be visible on the exterior of the product. These
are “weld lines” that result from the plastic molding process.
They are not cracks or scratches.
Musical Instrument Etiquette
Always be aware of others around you whenever using this
product. Be especially careful when playing late at night to
keep the volume at levels that do not disturb others. Other
steps you can take when playing late at night are closing the
window and using headphones.
AC Adaptor Handling Precautions
• Use a power outlet that is easily accessible so you can
unplug the AC adaptor when a malfunction occurs or
whenever else you need to do so.
• The AC adaptor is intended for indoor use only. Do not
use it where it might be exposed to splashing or moisture.
Do not place any container, such as a flower vase, that
contains liquid on the AC adaptor.
• Store the AC adaptor in a dry place.
• Use the AC adaptor in an open, well-ventilated area.
• Never cover the AC adaptor with newspaper, a table
cloth, a curtain, or any other similar item.
• Unplug the AC adaptor from the power outlet if you do not
plan to use the Digital Piano for a long time.
• Never try to repair the AC adaptor or modify it in any way.
• AC adaptor operating environment
Temperature: 0 to 40°C
Humidity: 10% to 90% RH
• Output polarity: &
Operating Precautions
You can use a computer to download music score data from
the CASIO Website.
For more information, visit the URL below.
http://world.casio.com/
About Music Score data
