Part names and functions – Pioneer BDR-XD08S Portable USB 3.2 Gen 1 Clamshell Optical Drive (Snow White Silver) User Manual
Page 16
16
BDR-XD08B / BDR-XD08S / BDR-XD08G
En
Front / Top
3
2
1
1
Power/Busy Indicator
Operation status is indicated as follows:
During Power ON: Lights dimly
During reading/writing: Lights
During disc cover open/close: Lights dimly
2
OPEN Button
Press to open the disc cover.
•
When this device is connected to a Mac
®
with a disc inserted, this function cannot be used due to
macOS
®
specifications. Please check the macOS User Guide for how to operate with a Mac.
PureRead mode display function
Press and hold the [OPEN] button to see the set PureRead mode. Refer to page 24 for details.
3
Disc Cover
Press the [OPEN] button to open the disc cover then place only a BD, DVD or CD disc onto the
tray with the label facing up. Close the disc cover gently.
Do not manually force open the disc cover.
Use the Forced Open Lever (see next page) to open the disc cover during POWER OFF.
WARNING
Take care not to let your hand or fingers become pinched by the cover.
Part Names and Functions
