Congratulations on your new Jackery Explorer 300 Plus. Please read this manual carefully before using
the product, particularly the relevant precautions to ensure proper use. Keep this manual in an
accessible place for frequent reference.
In compliance with laws and regulations, the right of final interpretation of this document and all related
documents of this product resides with the Company.
Please kindly notice that no further notifications will be given in case of any update, revision or
termination.
TECHNICAL SPECIFICATIONS
01
CERTIFICATIONS
Product Name
Model No.
Capacity
Weight
Dimensions
Cycle Life
Total Output
AC Output
USB-A Output
USB-C (OUT)
USB-C (IN/OUT)
USB Total Output
Car Port
Charge mode AC Input
Bypass mode AC Input/Output
DC Input(USB-C)
Charge Temperature
Discharge Temperature Jackery Explorer 300 Plus
JE-300B
Lithium-ion 22.5Ah / 12.8V DC(288Wh)
Around 8.27 Ibs / 3.75 kg
9.1 x 6.1 x 6.6 in / 23 x 15.5 x 16.7 cm
3000 cycles to 80%+ capacity
300W
120V~60Hz, 2.5A, 300W Rated, 600W Surge peak
15W Max 5V
⎓ 3A
15W Max 5V ⎓ 3A
100W Max 5V ⎓ 3A, 9V ⎓ 3A, 12V ⎓ 3A, 15V ⎓ 3A, 20V ⎓ 5A
USB-C(IN/OUT) : 100W Max, USB-C(OUT)+USB-A : 24W Max
12V
⎓ 10A
100V-120V~60Hz, 10A Max
100V-120V~60Hz, 300W Max
12-27V
⎓ 5A Max, 100W Max
0~45°C (32~113 ℉ )
-10~45°C (14~113 ℉ )
US
Model: JE-300B
English
USB Type-C and USB-C are registered trademarks of USB Implementers Forum. ® ®
PACKAGE LIST
3
AC Charge Cable
2 4 1
Jackery Explorer 300 Plus
DC7909 to USB-C
Adaptor
5
User Manual
Model: JE-300B
Contact us: [email protected] 1-888-502-2236(US)
USER MANUAL
Jackery Explorer 300 Plus
5
Version: JAK-UM-V1.0
