Jackery Explorer 300 Plus Portable Power Station with 40-Watt Solar Panel - Manual (Page 5)

03
15 13
11 10
EPS 18
12
WIFI
16 Bluetooth 17
14
Low Temperature Warning Remaining Discharge Time Output Power
AC Power Indicator Battery Power Indicator
US
Battery Power Indicator
When the product is being charged, the orange circle around the battery percentage will light
up in sequence. When charging other devices, the orange circle will stay on.
Low Battery Indicator
When the battery is less than 20%, the Low Battery Indicator will stay on. When less than 5%, the
Low Battery Indicator will flash. When it is being charged, the Indicator will be off.
EPS: Emergency Power System.
Once you have connected the mains and the AC input port of the EPS via the AC charger cable, you
can use the AC output port of the EPS to power your unit (at this point the AC power comes from the
mains, not the EPS battery). In the event of a sudden loss of mains power, the EPS can automatically
switch to battery mode within 20ms. Since this is a non-professional UPS function, it does not support
0ms switching. Do not connect to equipment with high uninterruptible power requirements such as
data servers and workstations. Please test several times to confirm compatibility before use and it is
recommended to connect to only one device. Do not use more than one unit at a time to avoid
triggering the overload protection. Failure to follow these instructions may result in equipment failure
or loss of data for which we cannot be held responsible.
Output Output Power Defaults
AC Output
All outputs turned off automatically after 12 hours
≤25W
≤2W
≤2W
USB Output
Car Output
Energy Saving Mode
To avoid forgetting to turn off the output which results in battery consumption, the product
turns the Energy Saving Mode on by default. This occurs when no device is connected or the
connected device is less than or equal to a certain value. (Refer to the table below for more
details), the device will automatically turn off all outputs after 12 hours.
To turn off the Energy Saving Mode
Long press the AC Button and Main Power Button until the Energy Saving Mode icon disappears.
In Non-Energy Saving Mode, please remember to turn off the products to avoid battery
consumption.
To turn on the Energy Saving Mode
Long press the AC Button and Main Power Button until the Low Power Mode icon lights up on
the screen.
Energy Saving Mode
