Jackery Explorer 300 Plus Portable Power Station with 40-Watt Solar Panel - Manual (Page 8)

06
Jackery New SolarSaga 40 Mini or 80 Solar Panel Connection Guide
The new SolarSaga 40 Mini is compatible with different models of portable power stations and contains
two ports:
* DC8020 port is suitable for Jackery Pro series and Plus series (excluding Explorer 300 Plus ).
*DC8020-DC7909 port applies to Jackery Explorer 160/240/300/500/1000.
3m
DC8020
3m
DC8020-DC7909
US
* Users who have already purchased the 80W solar panel, the following scheme shows how to connect
it to the Explorer 300 Plus.
* For the 40W solar panel included in the package, please also refer to the following connection
method to charge the Explorer 300 Plus
Explorer 300 Plus
SolarSaga 80
USB-C input port
DC8020 to DC7909 Adaptor
DC7909 to USB-C Adaptor
DC8020
3m
5
Explorer 300 Plus
SolarSaga 40
USB-C input port
DC8020 to DC7909 Adaptor
DC7909 to USB-C Adaptor
DC8020
3m
5
SolarSaga 40
SolarSaga 40
