Canon imageFORMULA DR-C240 Office Document Scanner - Manual (Page 88)

88
Appendix
Specifications
Main Unit
Type Desktop sheetfed scanner
Scanning Document Size
Plain Paper
Size: Width: 50.8mm to 216 mm (2" to 8.5")
Length: 54 mm to 356 mm (2.1" to 14") (You can
scan documents up to 3,000 mm (118.1") long by
setting the scanner to the Long Document mode.)
Paper weight: Page separation: 27 to 209 g/m 2 (7 to 56 lb bond)
0.04 mm to 0.25 mm (0.00157" to 0.00984")
Non separation: 27 to 255 g/m
2 (7 to 68 lb bond)
0.04 mm to 0.3 mm (0.00157" to 0.0118")
Loading capacity:
A4 size or smaller: 60 sheets (80g/m
2
(21 lb
bond))
Larger than A4 size: 40 sheets (80g/m
2
(21 lb
bond))
Make sure stacks do not exceed 6 mm in height for
either of the above.
Business Card
Size: 50.8 mm x 85 mm (2" x 3.35") or larger
Paper thickness:
380 g/m 2 (80 lb bond) 0.45 mm (0.0177") or
smaller
Card
Size: 54 mm x 86 mm (2.12" x 3.37") (ISO standard)
Card thickness: 1.4 mm (0.055") or smaller
Orientation:
Horizontal feeding only
Embossed cards can be scanned.
Loading capacity:
3 cards (non-embossed), 1 card (embossed)
Passport
Size: 88 mm x 125 mm (3.464" x 4.921") (ISO standard)
When scanning, be sure to open the passport and
insert it in the provided carrier sheet beforehand.
Thickness: 4 mm (0.157") or less (including carrier sheet)
Scanning Sensor Contact image sensor
Light source
LED
Scanning Side Simplex/duplex
Scanning modes Black and White, Error Diffusion, 256-level
Grayscale, Advanced Text Enhancement,
Advanced Text Enhancement II, 24-bit Color
Scanning resolution (Primary Scan Lines x Secondary Scan Lines)
100 x 100dpi/150 x 150dpi/200 x 200dpi/
240×240dpi/300 x 300dpi/400 x 400dpi/600 x
600dpi
Scanning Speed (Conditions: Core i7 2.8GHz CPU, 4 GB memory, A4
document size)
Grayscale Simplex 200dpi 45 pages/min.
300dpi 45 pages/min.
Duplex 200dpi 90 images/min.
300dpi 90 images/min.
24-bit Color Simplex 200dpi 30 pages/min.
300dpi 20 pages/min.
Duplex 200dpi 60 images/min.
300dpi 40 images/min.
Interface Hi-Speed USB 2.0
Other functions Folio scanning, double feed detection ignore
External Dimensions
291 mm (11.46")(W) x 253 mm (9.96")(D) x 231
mm (9.09")(H) (With the feed tray attached and the
document eject tray closed)
291 mm (11.46")(W) x 603 mm (23.74")(D) x 363
mm (14.29")(H) (With the feed tray attached and
the document eject tray open)
Weight (without AC adapter)
Aprpoximately 2.8 kg (6.17 lb)
Power Supply (using AC adapter)
DC24V 1.0A
Power Consumption
Scanning: Maximum 22 W
In the Sleep mode: Maximum 1.7 W
With power switch OFF: Maximum 0.5 W
Noise Not more than 59 dB
Operating Environment
Temperature: 10°C to 32.5°C (50°F to 90.5°F)
